Vortex Blue: Internal
The Grant VortexBlue combines our proven condensing boiler technology with a revolutionary new blue flame.
Using a new state-of-the-art Riello Blue Flame compact burner alongside the familiar Vortex oil-fired boiler, this market-leading combination gives you an easy to install, reliable product with those all-important low emissions.
a HeatingFeatures & benefits
The Grant VortexBlue internal models combine our existing proven condensing boiler technology with the latest Riello RDB BLU compact burner.
The boilers feature a sleek white casing, unique control panel with neon diagnostic indicators and simplified pipework arrangement, making them the ideal choice for utility room installations.
Sealed system
Sealed system versions are also available. These include a factory fitted expansion vessel, filling loop, pressure gauge, automatic air vent, pressure relief valve and high efficiency circulating pump, enabling boilers to be installed without the need for a feed and expansion tank in the loft
- Award winning range
- Outputs of 15-21, 21-26 and 26-36kW
- 90.7 - 93.3% Gross SAP2009 annual efficiency
- 10 year guarantee when installed by a G1 accredited installer (T&C’s apply)
- Market-leading Riello Blue Flame burner
- Familiar burner technology
- Sleek white casing
- Neon diagnostic indicators
- Compliant with September 2018 low NOx legislation
Blue flame technology
Grant and Riello’s R&D have together successfully matched and field trialled this new range of innovative appliances.
As the name suggests, the flame produced is blue in colour, rather than the usual yellow colour of the standard burners fitted in our current Grant Vortex range, which results in a much cleaner combustion process. All of the Grant VortexBlue boilers operate at the very high efficiency levels expected of the Grant Vortex condensing range and have the added benefit of producing extremely low NOx emissions.
From 26th September 2018, oil fired boilers installed in the UK will have to meet lower NOx emission targets. Furthermore, it is likely that even more stringent emission levels will be set in future years, so Grant have taken the decision to try and future proof oil fired appliances by moving to very low NOx, Blue Flame technology today.
Find a merchant
Use our national merchant search to find a Grant supplier near you
Configure your flue
We have a wide range of options available when it comes to flue systems, here's a helpful hand to put the right flue with the right boiler.
Use toolSpecification
Product code |
Model |
Set Output |
Max Output |
Weight |
Height |
Width |
Depth |
Efficiency |
NOx Emissions |
Tappings Flow/Return |
Burner |
Energy Rating |
Load Profile |
Energy Label |
Product Fiche |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VTXBF21 | Grant VortexBlue Internal 21 (15-21kW) | 21kW | 21kW | 130kg | 860mm | 470mm | 603mm | 90.81 | Class 3 | 22mm | Riello RDB Blu | a Heating | - | View | View |
| VTXBF26 | Grant VortexBlue Internal 26 (21-26kW) | 26kW | 26kW | 130kg | 860mm | 470mm | 603mm | 91.71 | Class 3 | 22mm | Riello RDB Blu | a Heating | - | View | View |
| VTXBF36 | Grant VortexBlue Internal 36 (26-36kW) | 36kW | 36kW | 144kg | 900mm | 470mm | 603mm | 94.56 | Class 3 | 28mm | Riello RDB Blu | a Heating | - | View | View |
| VTXSBF21 | Grant VortexBlue Internal System 21 (15-21kW) | 21kW | 21kW | 130kg | 860mm | 470mm | 603mm | 90.81 | Class 3 | 22mm | Riello RDB Blu | a Heating | - | View | View |
| VTXSBF26 | Grant VortexBlue Internal System 26 (21-26kW) | 26kW | 26kW | 130kg | 860 mm | 470 mm | 603mm | 91.71 | Class 3 | 22mm | Riello RDB Blu | a Heating | - | View | View |
| VTXSBF36 | Grant VortexBlue Internal System 36 (26-36kW) | 36kW | 36kW | 144kg | 900mm | 470mm | 603mm | 94.56 | Class 3 | 28mm | Riello RDB Blu | a Heating | - | View | View |
Downloads
Accessories
Grant Vortex Mag One Magnetic Filter
- Filters magnetite and non-ferrous debris
- Simple to install, easy to clean, easy to drain design
- 12000 gauss neodymium magnet
EZ Flues: Internal low level balanced flues (yellow system)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Self-sealing ducts requiring no silicone or tape
- Optional plume diverter (maximum height = 6 metres)
EZ-Fit Internal Vertical Balanced Flues (White System)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Unique connection system ensures easy assembly
- Supplied as a complete kit
EZ-Fit Internal High Level Balanced Flues (White System)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Maximum total flue length = 10 metres (deduct 1 metre for each additional 45° elbow used)
- Flue may be extended horizontally and vertically
EZ-Fit Flexible Vertical Balanced Flues (Red System)
- Suitable for Grant Vortex boilers up to 26kW
- Quick and simple to install
- Available in 6, 8, 10 and 12 metre packs
EZ-Fit Vertical conventional flues (Orange System)
- Suitable for Grant Vortex boilers up to 70kW
- Designed to enable an existing chimney to be utilised.
- Available in 6, 8, 10, 11, 12, 14 and 16 metre flexi packs
