Vortex Boiler House
The new Grant Vortex Boiler House models come in a distinctive powder coated casing in our iconic Grant red and feature an externally mounted Riello RDB burner and dual thermostat. They have high energy efficiency ratings which not only significantly lower fuel bills but also considerably reduce greenhouse gas emissions and lessen the environmental impact of domestic hot water and heating systems. Incorporating the latest Riello low NOx burner technology the Vortex Boiler House range meets the 2018 low NOx emission targets.
a HeatingFeatures & benefits
The Grant boiler House models are ideal for locations that are difficult to access like cellars or plant rooms, where a white cased utility version is not always the best solution.
The Boiler House models encompass the same unique stainless steel heat exchangers used in other Vortex boilers together with Grant’s exclusive turbulator baffle system which provides ultra-high efficiency and low running costs. These additions to the Vortex range are compatible with all Grant EZ-Fit Flue systems and are flued in exactly the same way as Utility models, further enhancing installation options.
- Compliant with September 2018 low NOx legislation
- Outputs ranging from 15–70kW
- 90.7 – 93.3% Gross SAP2009 annual efficiency
- 5 year guarantee when installed by a G1 accredited installer (T&C’s apply)
- Fitted with tried and trusted Riello RDB Lo-NOx burner
- Red powder coated steel casing
- Compact design - ideal for garage and cellar installations
- Simple and quick to install with no complicated wiring or plumbing
- Unique Grant Vortex stainless steel heat exchanger
Low NOx Ready
On 26th September 2018, the next phase of the EU’s Energy-related Products Directive will come into effect. New legislation will set maximum nitrogen oxides (NOx) emission levels that space heaters will need to meet, reducing the overall NOx emissions produced from heating. For oil-fired boilers, the NOx emissions target will be a maximum of 120mg/kWh so all oil boilers placed on the market by the manufacturer on or after 26th September will need to be compliant.
One of the overarching objectives of the new legislation is to help improve the air quality by reducing pollution. In response to both Government regulations and a growing demand from homeowners, manufacturers have continuously explored ways to make their products more efficient and sustainable. The good news is that advances with burner technology coupled to Grant’s efficient boiler designs have enabled all of our Vortex Pro and Eco boiler ranges to achieve these new targets with virtually no visible change to the existing line up.
Help me find the right heating system
Find the right heating system for your home using our product configurator tool
Use toolFind an engineer
Search our extensive engineer network and locate a technician in your area
Specification
Product code |
Model |
Set Output |
Max Output |
Weight |
Height |
Width |
Depth |
Efficiency |
NOx Emissions |
Energy Rating |
Load Profile |
Energy Label |
Product Fiche |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VTXBH1521 | Grant Vortex Boiler House 15-21 | 18kW | 21kW | 125kg | 714mm | 431mm | 597mm | 92.70 | Class 2 | a Heating | - | View | View |
| VTXBH2126 | Grant Vortex Boiler House 21-26 | 23.5kW | 26kW | 125kg | 714mm | 431mm | 597mm | 91.70 | Class 2 | a Heating | - | View | View |
| VTXBH2635 | Grant Vortex Boiler House 26-35 | 31kW | 35kW | 143kg | 714mm | 431mm | 597mm | 92.40 | Class 2 | a Heating | - | View | View |
| VTXBH3646 | Grant Vortex Boiler House 36-46 | 41kW | 46kW | 145kg | 703mm | 456mm | 592mm | 90.06 | Class 2 | a Heating | - | View | View |
| VTXBH4658 | Grant Vortex Boiler House 46-58 | 52kW | 58kW | 257kg | 1024mm | 543mm | 768mm | 91.98 | Class 2 | a Heating | - | View | View |
| VTXBH5870 | Grant Vortex Boiler House 58-70 | 64kW | 70kW | 301kg | 1024mm | 543mm | 768mm | 91.66 | Class 2 | a Heating | - | View | View |
Downloads
Accessories
Grant Vortex Mag One Magnetic Filter
- Filters magnetite and non-ferrous debris
- Simple to install, easy to clean, easy to drain design
- 12000 gauss neodymium magnet
Grant EZ Flues: Internal low level balanced flues (yellow system)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Self-sealing ducts requiring no silicone or tape
- Optional plume diverter (maximum height = 6 metres)
EZ-Fit Internal Vertical Balanced Flues (White System)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Unique connection system ensures easy assembly
- Supplied as a complete kit
EZ-Fit Internal High Level Balanced Flues (White System)
- Suitable for Internal Grant Vortex boilers up to 70kW
- Maximum total flue length = 10 metres (deduct 1 metre for each additional 45° elbow used)
- Flue may be extended horizontally and vertically
EZ-Fit Flexible Vertical Balanced Flues (Red System)
- Suitable for Grant Vortex boilers up to 26kW
- Quick and simple to install
- Available in 6, 8, 10 and 12 metre packs
EZ-Fit Vertical conventional flues (Orange System)
- Suitable for Grant Vortex boilers up to 70kW
- Designed to enable an existing chimney to be utilised.
- Available in 6, 8, 10, 11, 12, 14 and 16 metre flexi packs
